GAHP-GS - geothermal, takes heat from Ground and gives it to Water for heating or domestic hot water production
GAHP-GS Maximum outlet water temperature for heating/DHW 65/70°C, heating capacity 41.6 kW (B0/W35), G.U.E. gas utilization efficiency 165% (B0/W35), A++ energy class ErP on 55°C operation, gas (G20) consumption 2.67 m³/h, electrical power consumption 0.41 kW, sound pressure level (at 5 m distance) 44.1 dB(A), water connection 1¼", electrical degree of protection IP X5D, weight 300 kg, outside working temperature -15°C/+45°C, can be ordered with special winter kit for operation on lower temperature down to -30°C
GAHP-GS
Maximum outlet water temperature for heating/DHW 65/70°C, heating capacity 41.6 kW (B0/W35), G.U.E. gas utilization efficiency 165% (B0/W35), A++ energy class ErP on 55°C operation, gas (G20) consumption 2.67 m³/h, electrical power consumption 0.41 kW, sound pressure level (at 5 m distance) 44.1 dB(A), water connection 1¼", electrical degree of protection IP X5D, weight 300 kg, outside working temperature -15°C/+45°C, can be ordered with special winter kit for operation on lower temperature down to -30°C
Izvēlieties produkta modeli:
GAHP-GS geothermal gas absorption heat pump Ground/Water
Manuals 8.4 MB
Atbilstības deklarācijas 3.9 MB
Katalogi 3.5 MB
BIM objects 1.3 MB
Comfort Control Interface installation and use manual 798 KB
Multiple preassembled groups (Link) installation, user and maintenance manual 15 MB
DDC control panel
Manuals 12.4 MB
Bukleti 795 KB
MODBUS protocol for connection to BMS 690 KB
RB100 (Robur Box 100) control interface
Manuals 3.1 MB
RB200 (Robur Box 200) control interface
Manuals 3.1 MB
