Electric heat pump - Aura HCS454 E15 | Flowair

Izvēlieties produkta veidu un modeli:

Electric heat pump, reversible, on heating operation mode takes heat from Air and gives it to Water for heating, on cooling operation mode takes heat from Water for cooling and gives it to Air, monobloc design, can operate from -25°C to 45°C outside air temperature, integrated hydraulic pump, accumulation tank and expansion vessel, reversible, on heating operation mode takes heat from Air and gives it to Water for heating, on cooling operation mode takes heat from Water for cooling and gives it to Air, monobloc design, can operate from -25°C to 45°C outside air temperature, integrated hydraulic pump, accumulation tank and expansion vessel, delivered with anti-vibration mounting pads, with additional electric heater, 53.2 kW heating capacity at 45/40°C water and 7°C air temperature, 15 kW additional heating power by electric heater, energy consumption in heating mode 15.2+15 kW, COP 3.50, 47.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 15.0 kW, EER 3.16, sound pressure at 10 m distance 46 dB(A), weight 633 kg, 2 year WARRANTY
Vai jūs interesē šis produkts? Sazinieties ar mums:

Andrius Lekarevičius

LT, RU, EN
+370 606 11865

Latvijas tirdzniecības pārstāvja vietnieks Saņemt piedāvājumu
Noklikšķiniet uz modeļa: parādīsies tehniskā informācija, izmēri, piederumi
Aura - reversible, on heating operation mode takes heat from Air and gives it to Water for heating, on cooling operation mode takes heat from Water for cooling and gives it to Air, monobloc design, can operate from -25°C to 45°C outside air temperature, integrated hydraulic pump, accumulation tank and expansion vessel, delivered with anti-vibration mounting pads
Aura HCS113 12.5 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 3.4 kW, COP 3.68, 11.3 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 3.0 kW, EER 3.77, sound pressure at 10 m distance 43 dB(A), weight 283 kg, 2 year WARRANTY
Aura HCS113
12.5 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 3.4 kW, COP 3.68, 11.3 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 3.0 kW, EER 3.77, sound pressure at 10 m distance 43 dB(A), weight 283 kg, 2 year WARRANTY
Aura HCS219 18.4 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 5.1 kW, COP 3.61, 16.1 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 4.9 kW, EER 3.29, sound pressure at 10 m distance 46 dB(A), weight 371 kg, 2 year WARRANTY
Aura HCS219
18.4 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 5.1 kW, COP 3.61, 16.1 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 4.9 kW, EER 3.29, sound pressure at 10 m distance 46 dB(A), weight 371 kg, 2 year WARRANTY
Aura HCS325 24.8 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 6.9 kW, COP 3.59, 22.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 6.5 kW, EER 3.45, sound pressure at 10 m distance 46 dB(A), weight 484 kg, 2 year WARRANTY
Aura HCS325
24.8 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 6.9 kW, COP 3.59, 22.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 6.5 kW, EER 3.45, sound pressure at 10 m distance 46 dB(A), weight 484 kg, 2 year WARRANTY
Aura HCS332 31.7 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 8.6 kW, COP 3.69, 28.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 8.1 kW, EER 3.56, sound pressure at 10 m distance 47 dB(A), weight 508 kg, 2 year WARRANTY
Aura HCS332
31.7 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 8.6 kW, COP 3.69, 28.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 8.1 kW, EER 3.56, sound pressure at 10 m distance 47 dB(A), weight 508 kg, 2 year WARRANTY
Aura HCS444 43.1 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 12.4 kW, COP 3.48, 38.5 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 12.0 kW, EER 3.21, sound pressure at 10 m distance 49 dB(A), weight 597 kg, 2 year WARRANTY
Aura HCS444
43.1 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 12.4 kW, COP 3.48, 38.5 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 12.0 kW, EER 3.21, sound pressure at 10 m distance 49 dB(A), weight 597 kg, 2 year WARRANTY
Aura HCS454 53.2 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 15.2 kW, COP 3.50, 47.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 15.0 kW, EER 3.16, sound pressure at 10 m distance 46 dB(A), weight 633 kg, 2 year WARRANTY
Aura HCS454
53.2 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 15.2 kW, COP 3.50, 47.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 15.0 kW, EER 3.16, sound pressure at 10 m distance 46 dB(A), weight 633 kg, 2 year WARRANTY
Aura HCS563 62.6 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 18.2 kW, COP 3.44, 54.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 17.4 kW, EER 3.15, sound pressure at 10 m distance 49.8 dB(A), weight 779 kg, 2 year WARRANTY
Aura HCS563
62.6 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 18.2 kW, COP 3.44, 54.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 17.4 kW, EER 3.15, sound pressure at 10 m distance 49.8 dB(A), weight 779 kg, 2 year WARRANTY
Aura HCS575 74.6 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 21.4 kW, COP 3.49, 64.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 20.2 kW, EER 3.21, sound pressure at 10 m distance 48.9 dB(A), weight 806 kg, 2 year WARRANTY
Aura HCS575
74.6 kW heating capacity at 45/40°C water and 7°C air temperature, energy consumption in heating mode 21.4 kW, COP 3.49, 64.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 20.2 kW, EER 3.21, sound pressure at 10 m distance 48.9 dB(A), weight 806 kg, 2 year WARRANTY
Aura E - reversible, on heating operation mode takes heat from Air and gives it to Water for heating, on cooling operation mode takes heat from Water for cooling and gives it to Air, monobloc design, can operate from -25°C to 45°C outside air temperature, integrated hydraulic pump, accumulation tank and expansion vessel, reversible, on heating operation mode takes heat from Air and gives it to Water for heating, on cooling operation mode takes heat from Water for cooling and gives it to Air, monobloc design, can operate from -25°C to 45°C outside air temperature, integrated hydraulic pump, accumulation tank and expansion vessel, delivered with anti-vibration mounting pads, with additional electric heater
Aura HCS113 E4 12.5 kW heating capacity at 45/40°C water and 7°C air temperature, 4 kW additional heating power by electric heater, energy consumption in heating mode 3.4+4 kW, COP 3.68, 11.3 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 3.0 kW, EER 3.77, sound pressure at 10 m distance 43 dB(A), weight 283 kg, 2 year WARRANTY
Aura HCS113 E4
12.5 kW heating capacity at 45/40°C water and 7°C air temperature, 4 kW additional heating power by electric heater, energy consumption in heating mode 3.4+4 kW, COP 3.68, 11.3 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 3.0 kW, EER 3.77, sound pressure at 10 m distance 43 dB(A), weight 283 kg, 2 year WARRANTY
Aura HCS219 E6 18.4 kW heating capacity at 45/40°C water and 7°C air temperature, 6 kW additional heating power by electric heater, energy consumption in heating mode 5.1+6 kW, COP 3.61, 16.1 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 4.9 kW, EER 3.29, sound pressure at 10 m distance 46 dB(A), weight 371 kg, 2 year WARRANTY
Aura HCS219 E6
18.4 kW heating capacity at 45/40°C water and 7°C air temperature, 6 kW additional heating power by electric heater, energy consumption in heating mode 5.1+6 kW, COP 3.61, 16.1 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 4.9 kW, EER 3.29, sound pressure at 10 m distance 46 dB(A), weight 371 kg, 2 year WARRANTY
Aura HCS325 E8 24.8 kW heating capacity at 45/40°C water and 7°C air temperature, 8 kW additional heating power by electric heater, energy consumption in heating mode 6.9+8 kW, COP 3.59, 22.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 6.5 kW, EER 3.45, sound pressure at 10 m distance 46 dB(A), weight 484 kg, 2 year WARRANTY
Aura HCS325 E8
24.8 kW heating capacity at 45/40°C water and 7°C air temperature, 8 kW additional heating power by electric heater, energy consumption in heating mode 6.9+8 kW, COP 3.59, 22.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 6.5 kW, EER 3.45, sound pressure at 10 m distance 46 dB(A), weight 484 kg, 2 year WARRANTY
Aura HCS332 E9 31.7 kW heating capacity at 45/40°C water and 7°C air temperature, 9 kW additional heating power by electric heater, energy consumption in heating mode 8.6+9 kW, COP 3.69, 28.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 8.1 kW, EER 3.56, sound pressure at 10 m distance 47 dB(A), weight 508 kg, 2 year WARRANTY
Aura HCS332 E9
31.7 kW heating capacity at 45/40°C water and 7°C air temperature, 9 kW additional heating power by electric heater, energy consumption in heating mode 8.6+9 kW, COP 3.69, 28.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 8.1 kW, EER 3.56, sound pressure at 10 m distance 47 dB(A), weight 508 kg, 2 year WARRANTY
Aura HCS444 E12 43.1 kW heating capacity at 45/40°C water and 7°C air temperature, 12 kW additional heating power by electric heater, energy consumption in heating mode 12.4+12 kW, COP 3.48, 38.5 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 12.0 kW, EER 3.21, sound pressure at 10 m distance 49 dB(A), weight 597 kg, 2 year WARRANTY
Aura HCS444 E12
43.1 kW heating capacity at 45/40°C water and 7°C air temperature, 12 kW additional heating power by electric heater, energy consumption in heating mode 12.4+12 kW, COP 3.48, 38.5 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 12.0 kW, EER 3.21, sound pressure at 10 m distance 49 dB(A), weight 597 kg, 2 year WARRANTY
Aura HCS454 E15 53.2 kW heating capacity at 45/40°C water and 7°C air temperature, 15 kW additional heating power by electric heater, energy consumption in heating mode 15.2+15 kW, COP 3.50, 47.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 15.0 kW, EER 3.16, sound pressure at 10 m distance 46 dB(A), weight 633 kg, 2 year WARRANTY
Aura HCS454 E15
53.2 kW heating capacity at 45/40°C water and 7°C air temperature, 15 kW additional heating power by electric heater, energy consumption in heating mode 15.2+15 kW, COP 3.50, 47.4 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 15.0 kW, EER 3.16, sound pressure at 10 m distance 46 dB(A), weight 633 kg, 2 year WARRANTY
Aura HCS563 E18 62.6 kW heating capacity at 45/40°C water and 7°C air temperature, 18 kW additional heating power by electric heater, energy consumption in heating mode 18.2+18 kW, COP 3.44, 54.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 17.4 kW, EER 3.15, sound pressure at 10 m distance 49.8 dB(A), weight 779 kg, 2 year WARRANTY
Aura HCS563 E18
62.6 kW heating capacity at 45/40°C water and 7°C air temperature, 18 kW additional heating power by electric heater, energy consumption in heating mode 18.2+18 kW, COP 3.44, 54.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 17.4 kW, EER 3.15, sound pressure at 10 m distance 49.8 dB(A), weight 779 kg, 2 year WARRANTY
Aura HCS575 E24 74.6 kW heating capacity at 45/40°C water and 7°C air temperature, 24 kW additional heating power by electric heater, energy consumption in heating mode 21.4+24 kW, COP 3.49, 64.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 20.2 kW, EER 3.21, sound pressure at 10 m distance 48.9 dB(A), weight 806 kg, 2 year WARRANTY
Aura HCS575 E24
74.6 kW heating capacity at 45/40°C water and 7°C air temperature, 24 kW additional heating power by electric heater, energy consumption in heating mode 21.4+24 kW, COP 3.49, 64.8 kW cooling capacity at 7/12°C water and 35°C air temperature, energy consumption in cooling mode 20.2 kW, EER 3.21, sound pressure at 10 m distance 48.9 dB(A), weight 806 kg, 2 year WARRANTY
Modelis: Aura HCS454 E15
Vispārējie dati
Heating capacity at 45/40°C water and 7°C outside air temperature
kW
53,2
Heating capacity by additional electric heater
kW
15
Electricity consumption in heating mode at 45/40°C water and 7°C outside air temperature
kW
15,2 + 15
COP - heating coefficient of performance
3,50
Energy efficiency class for low-temperature applications in medium climate conditions (Regulation 811/2013)
A++
Cooling capacity at 7/12°C water and 35°C outside air temperature
kW
47,4
Electricity consumption in cooling mode at 7/12°C water and 35°C outside air temperature
kW
15,0
EER - cooling energy efficiency ratio
3,16
Compressor system
Number of compressors
2
Number of circuits
1
Evaporator type
Plate
Number of fans
2
Hydraulic system
Water flow in heating mode
m³/h
9,2
Pressure drop in heating mode
kPa
28,8
Hydraulic connection
DN
40
Expansion vessel
dm³
18
Accumulation tank
dm³
200
Water pump power
kW
2,20
Electrical data
Power supply
V/Ph/Hz
400/3/50
Acoustic data
Sound power level according to ISO9614
dB(A)
82,1
Sound pressure level at a distance of 10 m from the unit
dB(A)
46,0
Izmēri
Garums
mm
2000
Platums
mm
1100
Augstums
mm
1750
Svars
kg
633
Aura electric heat pump Air/Water
Manuals 2.2 MB
Bukleti 3.3 MB
Presentation 6.8 MB
Modelis: Aura HCS454 E15
Additional control panels for Aura heat pumps
TW-AUR-HCS454-PO Additional control panel for Aura HCS454 heat pump operator, enables changing basic operating parameters and monitoring of the unit’s operation, can be mounted on the unit or inside building
TW-AUR-HCS454-PO
Additional control panel for Aura HCS454 heat pump operator, enables changing basic operating parameters and monitoring of the unit’s operation, can be mounted on the unit or inside building
Mechanical hydraulic filters for Aura heat pumps
TW-AUR-HCS454-FM Mechanical filter of the water / glycol circuit in Aura HCS454 heat pump, mounted outside the device at the hydraulic inlet, provides protection against mechanical contamination
TW-AUR-HCS454-FM
Mechanical filter of the water / glycol circuit in Aura HCS454 heat pump, mounted outside the device at the hydraulic inlet, provides protection against mechanical contamination
Hydraulic connections vibro-compensators for Aura heat pumps
TW-AUR-HCS454-WK Hydraulic connections vibro-compensators for Aura HCS454 heat pump, it ensures a flexible installation of the hydraulic system
TW-AUR-HCS454-WK
Hydraulic connections vibro-compensators for Aura HCS454 heat pump, it ensures a flexible installation of the hydraulic system
