Roof mounted extraction fan - TNE/H 634/6 T | Aspirnova

Name: Roof mounted extraction fan - TNE/H 634/6 T | Aspirnova
Brand: Aspirnova
Availability: PreOrder

Izvēlieties produkta modeli:

Modelis:

Roof mounted extraction fan, axial, with horizontal outlet, weather cover made of ABS plastic, allowed extracted air temperature range from -20ºC to +50ºC, IP55/F protection / insulation class, two speed motor, 15800/9820 m³/h air flow, max. static pressure 240/95 Pa, power consumption 1700/600 W, fan rotation speed 1400/900 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY

Ražotājs:

Vai jūs interesē šis produkts? Sazinieties ar mums:

Andrius Lekarevičius

LT, RU, EN
+370 606 11865

Latvijas tirdzniecības pārstāvja vietnieks Saņemt piedāvājumu

Noklikšķiniet uz modeļa: parādīsies tehniskā informācija, izmēri, piederumi

TNE/H - axial, with horizontal outlet, weather cover made of ABS plastic, allowed extracted air temperature range from -20ºC to +50ºC, IP55/F protection / insulation class
	TNE/H 404 M	4400 m³/h air flow, max. static pressure 130 Pa, power consumption 180 W, fan rotation speed 1400 rpm, weight 36 kg, one-phase connection, 2 year WARRANTY
		TNE/H 404 M
		4400 m³/h air flow, max. static pressure 130 Pa, power consumption 180 W, fan rotation speed 1400 rpm, weight 36 kg, one-phase connection, 2 year WARRANTY
	TNE/H 404 T	4400 m³/h air flow, max. static pressure 130 Pa, power consumption 180 W, fan rotation speed 1400 rpm, weight 36 kg, three-phase connection, 2 year WARRANTY
		TNE/H 404 T
		4400 m³/h air flow, max. static pressure 130 Pa, power consumption 180 W, fan rotation speed 1400 rpm, weight 36 kg, three-phase connection, 2 year WARRANTY
	TNE/H 406 T	2850 m³/h air flow, max. static pressure 50 Pa, power consumption 180 W, fan rotation speed 900 rpm, weight 36 kg, three-phase connection, 2 year WARRANTY
		TNE/H 406 T
		2850 m³/h air flow, max. static pressure 50 Pa, power consumption 180 W, fan rotation speed 900 rpm, weight 36 kg, three-phase connection, 2 year WARRANTY
	TNE/H 404/6 T	Two speed motor, 4400/2850 m³/h air flow, max. static pressure 130/50 Pa, power consumption 260/90 W, fan rotation speed 1400/900 rpm, weight 36 kg, three-phase connection, 2 year WARRANTY
		TNE/H 404/6 T
		Two speed motor, 4400/2850 m³/h air flow, max. static pressure 130/50 Pa, power consumption 260/90 W, fan rotation speed 1400/900 rpm, weight 36 kg, three-phase connection, 2 year WARRANTY
	TNE/H 454 M	7050 m³/h air flow, max. static pressure 120 Pa, power consumption 370 W, fan rotation speed 1400 rpm, weight 44 kg, one-phase connection, 2 year WARRANTY
		TNE/H 454 M
		7050 m³/h air flow, max. static pressure 120 Pa, power consumption 370 W, fan rotation speed 1400 rpm, weight 44 kg, one-phase connection, 2 year WARRANTY
	TNE/H 454 T	7050 m³/h air flow, max. static pressure 120 Pa, power consumption 370 W, fan rotation speed 1400 rpm, weight 44 kg, three-phase connection, 2 year WARRANTY
		TNE/H 454 T
		7050 m³/h air flow, max. static pressure 120 Pa, power consumption 370 W, fan rotation speed 1400 rpm, weight 44 kg, three-phase connection, 2 year WARRANTY
	TNE/H 456 T	4570 m³/h air flow, max. static pressure 65 Pa, power consumption 180 W, fan rotation speed 900 rpm, weight 44 kg, three-phase connection, 2 year WARRANTY
		TNE/H 456 T
		4570 m³/h air flow, max. static pressure 65 Pa, power consumption 180 W, fan rotation speed 900 rpm, weight 44 kg, three-phase connection, 2 year WARRANTY
	TNE/H 454/6 T	Two speed motor, 7050/4650 m³/h air flow, max. static pressure 120/65 Pa, power consumption 370/120 W, fan rotation speed 1400/900 rpm, weight 44 kg, three-phase connection, 2 year WARRANTY
		TNE/H 454/6 T
		Two speed motor, 7050/4650 m³/h air flow, max. static pressure 120/65 Pa, power consumption 370/120 W, fan rotation speed 1400/900 rpm, weight 44 kg, three-phase connection, 2 year WARRANTY
	TNE/H 504 M	9200 m³/h air flow, max. static pressure 145 Pa, power consumption 550 W, fan rotation speed 1400 rpm, weight 55 kg, one-phase connection, 2 year WARRANTY
		TNE/H 504 M
		9200 m³/h air flow, max. static pressure 145 Pa, power consumption 550 W, fan rotation speed 1400 rpm, weight 55 kg, one-phase connection, 2 year WARRANTY
	TNE/H 504 T	9200 m³/h air flow, max. static pressure 145 Pa, power consumption 550 W, fan rotation speed 1400 rpm, weight 55 kg, three-phase connection, 2 year WARRANTY
		TNE/H 504 T
		9200 m³/h air flow, max. static pressure 145 Pa, power consumption 550 W, fan rotation speed 1400 rpm, weight 55 kg, three-phase connection, 2 year WARRANTY
	TNE/H 506 T	6000 m³/h air flow, max. static pressure 65 Pa, power consumption 180 W, fan rotation speed 900 rpm, weight 55 kg, three-phase connection, 2 year WARRANTY
		TNE/H 506 T
		6000 m³/h air flow, max. static pressure 65 Pa, power consumption 180 W, fan rotation speed 900 rpm, weight 55 kg, three-phase connection, 2 year WARRANTY
	TNE/H 504/6 T	Two speed motor, 9200/6000 m³/h air flow, max. static pressure 145/65 Pa, power consumption 550/180 W, fan rotation speed 1400/900 rpm, weight 55 kg, three-phase connection, 2 year WARRANTY
		TNE/H 504/6 T
Two speed motor, 9200/6000 m³/h air flow, max. static pressure 145/65 Pa, power consumption 550/180 W, fan rotation speed 1400/900 rpm, weight 55 kg, three-phase connection, 2 year WARRANTY
TNE/H 564 M		13300 m³/h air flow, max. static pressure 225 Pa, power consumption 1100 W, fan rotation speed 1400 rpm, weight 65 kg, one-phase connection, 2 year WARRANTY
	TNE/H 564 M
	13300 m³/h air flow, max. static pressure 225 Pa, power consumption 1100 W, fan rotation speed 1400 rpm, weight 65 kg, one-phase connection, 2 year WARRANTY
TNE/H 564 T	13300 m³/h air flow, max. static pressure 225 Pa, power consumption 1100 W, fan rotation speed 1400 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
	TNE/H 564 T
	13300 m³/h air flow, max. static pressure 225 Pa, power consumption 1100 W, fan rotation speed 1400 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
TNE/H 566 T	8150 m³/h air flow, max. static pressure 85 Pa, power consumption 370 W, fan rotation speed 900 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
	TNE/H 566 T
	8150 m³/h air flow, max. static pressure 85 Pa, power consumption 370 W, fan rotation speed 900 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
TNE/H 568 T	6450 m³/h air flow, max. static pressure 50 Pa, power consumption 120 W, fan rotation speed 700 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
	TNE/H 568 T
	6450 m³/h air flow, max. static pressure 50 Pa, power consumption 120 W, fan rotation speed 700 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
TNE/H 564/6 T	Two speed motor, 13300/8150 m³/h air flow, max. static pressure 225/85 Pa, power consumption 1100/370 W, fan rotation speed 1400/900 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
	TNE/H 564/6 T
	Two speed motor, 13300/8150 m³/h air flow, max. static pressure 225/85 Pa, power consumption 1100/370 W, fan rotation speed 1400/900 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
TNE/H 566/8 T	Two speed motor, 8150/6450 m³/h air flow, max. static pressure 85/50 Pa, power consumption 370/150 W, fan rotation speed 900/700 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
	TNE/H 566/8 T
	Two speed motor, 8150/6450 m³/h air flow, max. static pressure 85/50 Pa, power consumption 370/150 W, fan rotation speed 900/700 rpm, weight 65 kg, three-phase connection, 2 year WARRANTY
TNE/H 634 T	17100 m³/h air flow, max. static pressure 240 Pa, power consumption 1500 W, fan rotation speed 1400 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
	TNE/H 634 T
	17100 m³/h air flow, max. static pressure 240 Pa, power consumption 1500 W, fan rotation speed 1400 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
TNE/H 636 T	10600 m³/h air flow, max. static pressure 95 Pa, power consumption 370 W, fan rotation speed 900 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
	TNE/H 636 T
	10600 m³/h air flow, max. static pressure 95 Pa, power consumption 370 W, fan rotation speed 900 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
TNE/H 638 T	8000 m³/h air flow, max. static pressure 55 Pa, power consumption 180 W, fan rotation speed 700 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
	TNE/H 638 T
	8000 m³/h air flow, max. static pressure 55 Pa, power consumption 180 W, fan rotation speed 700 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
TNE/H 634/6 T	Two speed motor, 15800/9820 m³/h air flow, max. static pressure 240/95 Pa, power consumption 1700/600 W, fan rotation speed 1400/900 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
	TNE/H 634/6 T
	Two speed motor, 15800/9820 m³/h air flow, max. static pressure 240/95 Pa, power consumption 1700/600 W, fan rotation speed 1400/900 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
TNE/H 636/8 T	Two speed motor, 10600/8000 m³/h air flow, max. static pressure 95/55 Pa, power consumption 370/150 W, fan rotation speed 900/700 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
	TNE/H 636/8 T
	Two speed motor, 10600/8000 m³/h air flow, max. static pressure 95/55 Pa, power consumption 370/150 W, fan rotation speed 900/700 rpm, weight 80 kg, three-phase connection, 2 year WARRANTY
TNE/H 716 T	16700 m³/h air flow, max. static pressure 105 Pa, power consumption 750 W, fan rotation speed 900 rpm, weight 90 kg, three-phase connection, 2 year WARRANTY
	TNE/H 716 T
	16700 m³/h air flow, max. static pressure 105 Pa, power consumption 750 W, fan rotation speed 900 rpm, weight 90 kg, three-phase connection, 2 year WARRANTY
TNE/H 718 T	12400 m³/h air flow, max. static pressure 55 Pa, power consumption 370 W, fan rotation speed 700 rpm, weight 90 kg, three-phase connection, 2 year WARRANTY
	TNE/H 718 T
	12400 m³/h air flow, max. static pressure 55 Pa, power consumption 370 W, fan rotation speed 700 rpm, weight 90 kg, three-phase connection, 2 year WARRANTY
TNE/H 716/8 T	Two speed motor, 16700/12400 m³/h air flow, max. static pressure 105/55 Pa, power consumption 1250/600 W, fan rotation speed 900/700 rpm, weight 90 kg, three-phase connection, 2 year WARRANTY
	TNE/H 716/8 T
	Two speed motor, 16700/12400 m³/h air flow, max. static pressure 105/55 Pa, power consumption 1250/600 W, fan rotation speed 900/700 rpm, weight 90 kg, three-phase connection, 2 year WARRANTY
TNE/H 806 T	25400 m³/h air flow, max. static pressure 130 Pa, power consumption 1500 W, fan rotation speed 900 rpm, weight 105 kg, three-phase connection, 2 year WARRANTY
	TNE/H 806 T
	25400 m³/h air flow, max. static pressure 130 Pa, power consumption 1500 W, fan rotation speed 900 rpm, weight 105 kg, three-phase connection, 2 year WARRANTY
TNE/H 808 T	18800 m³/h air flow, max. static pressure 65 Pa, power consumption 550 W, fan rotation speed 700 rpm, weight 105 kg, three-phase connection, 2 year WARRANTY
	TNE/H 808 T
	18800 m³/h air flow, max. static pressure 65 Pa, power consumption 550 W, fan rotation speed 700 rpm, weight 105 kg, three-phase connection, 2 year WARRANTY
TNE/H 806/8 T	Two speed motor, 25400/18800 m³/h air flow, max. static pressure 130/65 Pa, power consumption 1250/600 W, fan rotation speed 900/700 rpm, weight 105 kg, three-phase connection, 2 year WARRANTY
	TNE/H 806/8 T
	Two speed motor, 25400/18800 m³/h air flow, max. static pressure 130/65 Pa, power consumption 1250/600 W, fan rotation speed 900/700 rpm, weight 105 kg, three-phase connection, 2 year WARRANTY
TNE/H 906 T	33800 m³/h air flow, max. static pressure 145 Pa, power consumption 2200 W, fan rotation speed 900 rpm, weight 135 kg, three-phase connection, 2 year WARRANTY
	TNE/H 906 T
	33800 m³/h air flow, max. static pressure 145 Pa, power consumption 2200 W, fan rotation speed 900 rpm, weight 135 kg, three-phase connection, 2 year WARRANTY
TNE/H 908 T	25000 m³/h air flow, max. static pressure 80 Pa, power consumption 1100 W, fan rotation speed 700 rpm, weight 135 kg, three-phase connection, 2 year WARRANTY
	TNE/H 908 T
	25000 m³/h air flow, max. static pressure 80 Pa, power consumption 1100 W, fan rotation speed 700 rpm, weight 135 kg, three-phase connection, 2 year WARRANTY
TNE/H 906/8 T	Two speed motor, 33800/25000 m³/h air flow, max. static pressure 145/80 Pa, power consumption 2200/1100 W, fan rotation speed 900/700 rpm, weight 135 kg, three-phase connection, 2 year WARRANTY
	TNE/H 906/8 T
	Two speed motor, 33800/25000 m³/h air flow, max. static pressure 145/80 Pa, power consumption 2200/1100 W, fan rotation speed 900/700 rpm, weight 135 kg, three-phase connection, 2 year WARRANTY
TNE/H 1006 T	43700 m³/h air flow, max. static pressure 180 Pa, power consumption 3000 W, fan rotation speed 900 rpm, weight 155 kg, three-phase connection, 2 year WARRANTY
	TNE/H 1006 T
	43700 m³/h air flow, max. static pressure 180 Pa, power consumption 3000 W, fan rotation speed 900 rpm, weight 155 kg, three-phase connection, 2 year WARRANTY
TNE/H 1008 T	33000 m³/h air flow, max. static pressure 100 Pa, power consumption 1500 W, fan rotation speed 700 rpm, weight 155 kg, three-phase connection, 2 year WARRANTY
	TNE/H 1008 T
	33000 m³/h air flow, max. static pressure 100 Pa, power consumption 1500 W, fan rotation speed 700 rpm, weight 155 kg, three-phase connection, 2 year WARRANTY
TNE/H 1006/8 T	Two speed motor, 43700/33000 m³/h air flow, max. static pressure 180/100 Pa, power consumption 3500/1500 W, fan rotation speed 900/700 rpm, weight 155 kg, three-phase connection, 2 year WARRANTY
	TNE/H 1006/8 T
	Two speed motor, 43700/33000 m³/h air flow, max. static pressure 180/100 Pa, power consumption 3500/1500 W, fan rotation speed 900/700 rpm, weight 155 kg, three-phase connection, 2 year WARRANTY

Izmēri

Modelis: TNE/H 634/6 T

SG-TNE square shape roof mounted gravity shutters
	SG-TNE 630	Square shape gravity shutter for 630 size TNE/H roof mounted axial fans
	SG-TNE 630
	Square shape gravity shutter for 630 size TNE/H roof mounted axial fans
